WebMCP - another facet of remote agent control

Technical Discussion
1

This is distinct but related to the concept of exposing UI widgets directly via MCP. This technology isn’t meant to be used in a headless scenario, more of a way to give agents a leg up when using browser control, but it still seems very much related.

2

Will you be investigating this for use with moqui-mcp?

3

I haven’t been able to dive too deeply into this yet, but I ask Gemini if and how it would benefit the work that I have been doing (code named “blueprints”) and here is the conclusion:

ntegrating WebMCP with MoquiAi Blueprints would bridge the gap between human-first UIs and agent-first APIs without duplicating effort. By adding WebMCP hook generation into the

BlueprintClient.js renderer, every Moqui screen built with blueprints would automatically become an interactive, agent-ready playground . The AI interacts safely with the frontend architecture, while the user maintains final visual verification and control over the app state.

4

I had Gemini install webmcp last night. It took almost 4 hours. I had it generate a report detailing what it took to install. I’m not sure how applicable it will be to someone else trying to do the same thing, but I am a big believer and open sharing. It would require Ean’s moqui-mcp repo (GitHub - schue/moqui-mcp: MCP component for Moqui · GitHub) and my moqui-ai (GitHub - byersa/moqui-ai: Implements Moqui generation by bridging the use of Antigravity with moqui-mcp · GitHub). Here is the contents of the report md file:

Implementing WebMCP in the Moqui Ecosystem

This report details the integration of WebMCP within a Moqui environment. It explains how WebMCP extends the core moqui-mcp infrastructure to provide a bi-directional communication bridge between Moqui’s server-side logic and the user’s browser context.

1. The Architecture: moqui-mcp vs. webmcp

To understand the system, we must distinguish between the two core components:

A. moqui-mcp (The Backend)

Provides the server-side infrastructure for AI interaction.

  • EnhancedMcpServlet: Exposes standard MCP endpoints (/mcp/sse, /mcp/message).
  • Semantic Rendering: Includes custom FTL templates that transform Moqui screens into AI-optimized Markdown/JSON structures (Unified Semantic Layer).
  • Security: Implements McpAuthFilter to protect endpoints.

B. webmcp (The Frontend Bridge)

Provides the browser-side presence and the communication bridge.

  • webmcp.js: A client-side library that renders the interactive AI widget (the “Blue Square”) and handles browser-specific tool execution (DOM reading, screenshotting, navigation).
  • websocket-server.js: A Node.js bridge that allows external AI agents to connect to the browser session using secure tokens.

2. Installation Instructions

Step 1: Component Dependencies

Ensure both moqui-mcp and moqui-ai are present in your runtime/component directory.

Step 2: Global Resource Mounting

The modern way to install WebMCP is to mount it as a global subscreen in your root MoquiConf.xml. This ensures that JavaScript resources and Pinia stores are available across all Moqui components (e.g., HiveMind, PopCommerce, Aitree).

Add the following to your runtime/component/moqui-ai/MoquiConf.xml:

<screen-facade>
    <!-- Mount webmcp resources into the standard webroot context -->
    <screen location="component://webroot/screen/webroot.xml">
        <subscreens-item name="moqui-ai" menu-include="false"
                         location="component://moqui-ai/screen/moquiai.xml"/>
    </screen>
</screen-facade>

Step 3: Serving JS Resources

Modify moqui-ai/screen/moquiai.xml to serve nested JavaScript files (required for modular stores and utilities):

<screen xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
        xsi:noNamespaceSchemaLocation="http://moqui.org/xsd/xml-screen-3.xsd"
        allow-extra-path="true">
    <transitions>
        <transition name="js">
            <parameter name="extraPathNameList"/>
            <actions>
                <script>
                    def path = sri.screenUrlInfo.extraPathNameList.join("/")
                    ec.web.sendResourceResponse("component://moqui-ai/screen/moquiai/js/${path}")
                </script>
            </actions>
            <default-response type="none"/>
        </transition>
    </transitions>
</screen>

Step 4: UI Initialization

To activate the WebMCP widget on a screen, include the webmcp.js script. For a global application (like a Vue 3/Quasar app), add this to your PreActions or Main screen:

// In AitreePreActions.groovy or similar
def webmcpUrl = "/moqui-ai/js/webmcp.js"
if (footer_scripts_list != null) footer_scripts_list.add(webmcpUrl)

Step 5: Start the Bridge Server

WebMCP requires a small Node.js process to bridge the AI agent to the browser:

cd runtime/component/moqui-ai/screen/moquiai/js
node websocket-server.js --mcp

3. Benefits of WebMCP

Going forward, the WebMCP + moqui-mcp combination provides several strategic advantages for the Moqui community:

1. Unified Semantic Layer

By using Moqui’s screen-text-output logic (provided by moqui-mcp), the AI doesn’t just “see” HTML. It receives a semantic representation of the screen—entities, fields, and actions—making code generation and debugging significantly more accurate.

2. “Eyes and Ears” for the AI

Standard MCP servers are blind. They can only see the data the server sends them. WebMCP gives the AI vision. It can:

  • Capture screenshots to verify UI layout.
  • Inspect the live DOM to see how Vue/Quasar rendered a component.
  • “Push” actions into the browser (like opening a specific modal or tab) to guide the developer.

3. Decoupled Tooling

Because WebMCP uses a token-based WebSocket bridge, developers can use a variety of AI clients (VS Code, web-based LLMs, custom agents) to collaborate on the same browser session without modifying Moqui’s core security model.

4. Component Portability

By mounting WebMCP at the webroot level, any component in the Moqui ecosystem can immediately benefit from AI-assisted debugging and interaction by simply referencing the global /moqui-ai/js/ path.

4. Conclusion

WebMCP is not just a widget; it is the Interactive Development Environment (IDE) for the AI Era inside Moqui. By bridging the gap between Moqui’s rich entity-driven backend and the modern reactive frontend, it enables a level of AI pairing that was previously impossible.
